Full Automatic Oval Screen Printing Machine, WTKY
The XF swing (180°) fully automatic cylinder screen printing machine is an automatic flat screen press designed for high efficiency operation (significantly highly than diploid printing). The high precision printer is suitable for printing in bulk screen production. The equipment is compatible with 120-350gsm materials often used for paper products including wine cases, toiletry packages, posters and many others.
Specification
| Model | XF-720 |
XF-780 |
XF-1020 |
| Max. paper dimension | 720×520mm | 780×540mm | 1020×720mm |
| Min. paper dimension | 350×270mm | 350×270mm | 560×350mm |
| Max. printing dimension | 720×500mm | 780×520mm | 1020×700mm |
| Paper thickness | 120-400gsm | 120-400gsm | 120-400gsm |
| Border | ≤15mm | ≤15mm | ≤15mm |
| Printing plate dimension | 880×880mm | 940×940mm | 1280×1140mm |
| Max. printing speed | 1000-3600pcs/h | 1000-3300pcs/h | 1000-3000pcs/h |
| Power | 10.22kw | 10.22kw | 10.32kw |
| Weight | 3500kg | 3800kg | 4900kg |
| Overall dimensions | 4100×1200×1270mm | 4100×2100×1270mm | 4570×2700×1430mm |
-
